Processing Range

φ2.0-φ120mm
Max Length of Cut-in Mill 300mm

Motor

For Grinding Wheel 22kW 4P
For Guide Wheel 2.2kW 6P
For Cooling0.4kW 2P

Spindle Unit

Spindle Roller Bearing Double Support Type Grinding Wheel
Spindle Roller Bearing Double Support Type Guiding Wheel

Specification of Grinding Wheel

610×305×304.8mm(Outer Diameter×Width×Bore Diameter)

Specification of Guiding Wheel

330×305×203.2mm(Outer Diameter×Width×Bore Diameter)

Rotational Speed

Grinding Wheel1400rpm(MAX.1560rpm)
Linear Speed 45m/s(MAX.50m/s)
Stepless Variable-frequency Speed Regulation of Guide Wheel 12-230rpm

Electric Control Device

FANUC numerical control system

Power Supply Voltage

AC380V, Frequency 50Hz

Control Voltage

AC100V/110V;DC24V

Tilting Angle of Guiding Wheel

﹢5°-﹣5°

Floor Area

3050×2700mm(Width×Length)

Machine Tool Weight

About 7.5t
