Processing Range

φ1.6-φ120mm
Max Length of Cut-in Mill200mm

Motor

For Grinding Wheel11kW 4P
For Guide Wheel1.5kW 6P
For Cooling0.25kW 2P

Spindle Unit

Spindle Roller Bearing Cantilever Support Type Grinding Wheel
Spindle Roller Bearing Double Support Type Guiding Wheel

Specification of Grinding Wheel

610×205×304.8mm(Outer Diameter×Width×Bore Diameter)

Specification of Guide Wheel

330×205×203.2mm(Outer Diameter×Width×Bore Diameter)

Rotational Speed

Grinding Wheel 1400rpm(MAX.1875rpm)
Linear Speed 45m/s(MAX.60m/s)
Stepless Variable-frequency Speed Regulation of Guiding Wheel12-230rpm

Electric Control Device

FANUC Numerical Control System

Power Supply Voltage

AC380V, Frequency 50Hz

Control Voltage

AC100V/110V;DC24V

Tilting Angle of Guide Wheel

﹢5°-﹣5°

Floor Area

3050×2700mm(Width×Length)

Machine Tool Weight

About 7t
